6 KV High Voltage Tracking Index Rubber Test Machine IEC60587 Standards

6 KV High Voltage Tracking Index Rubber Test  Machine IEC60587 Standards
large.img.alt
6 KV High Voltage Tracking Index Rubber Test  Machine IEC60587 Standards 6 KV High Voltage Tracking Index Rubber Test  Machine IEC60587 Standards 6 KV High Voltage Tracking Index Rubber Test  Machine IEC60587 Standards 6 KV High Voltage Tracking Index Rubber Test  Machine IEC60587 Standards 6 KV High Voltage Tracking Index Rubber Test  Machine IEC60587 Standards 6 KV High Voltage Tracking Index Rubber Test  Machine IEC60587 Standards 6 KV High Voltage Tracking Index Rubber Test  Machine IEC60587 Standards

Large Image :  6 KV High Voltage Tracking Index Rubber Test Machine IEC60587 Standards

Product Details:
Place of Origin: China
Brand Name: Daxian
Certification: IEC60587-2007, ASTM D2303
Model Number: DX8427
Payment & Shipping Terms:
Minimum Order Quantity: One set
Price: Negotiation
Packaging Details: Wooden case
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 5 sets per month

6 KV High Voltage Tracking Index Rubber Test Machine IEC60587 Standards

Description
Power: AC 220V/50HZ Usage: Plastic Tester
Standards: IEC60587-2007 Drop Height: 30mm ~ 40mm Adjustable
Test Voltage: 100~6000V Adjustable Warranty: 12 Months
High Light:

vertical flammability chamber

,

textile flammability testing

IEC60587 6 KV Automatic High Voltage Tracking Index Tester

Technical Description:



This product is used in electrical products under the influence of moisture and impurity environment, between the different polarity of the live parts or between the live parts and the grounding metal parts may cause insulation on the leakage, the resulting arc caused by electrical breakdown of the electrical or due to Discharge causes the material to erode and even ignite the fire.





Standard:


IEC60587-2007, ASTM D2303

Parameters:



Box

≥ 0.5 cubic meters

Drop size

44 to 50 drops / cm3

Power supply

AC 220V, 50Hz

Electrical load

100 ~ 600V adjustable

Drip height

30mm ~ 40mm adjustable

Electrode Pressure

1.00N±0.05N

Flow range  0.00185 to 2 ml / min
Working speed  0.1 to 15 rev / min


6 KV High Voltage Tracking Index Rubber Test  Machine IEC60587 Standards 0

6 KV High Voltage Tracking Index Rubber Test  Machine IEC60587 Standards 1




Test voltage, series resistance and Pollution liquid flow rate table:

Test voltage range(KV) Tracking recommend voltage (KV)

Pollution liquid flow

rate (ml/min)

Series resistance



1.0 ~ 1.75 - 0.075 1
2.0 ~ 2.75 2.5 0.15 10
3.0 ~ 3.75 3.5 0.30 22
4.0 ~ 4.75 4.5 0.60 33
5.0 ~ 6.0 - 0.90 33



Our Advantage:

1. ISO9001:2008 certification

2. Professional and rich experienced staff

3. Both standard and Non-standard service are provides

4. 95% products export to foreigner countries

5 .Best service after shipment with emails.



6 KV High Voltage Tracking Index Rubber Test  Machine IEC60587 Standards 2
