Portable Fire Extinguisher Impact Test Machine
Meet the standards:
FAA's Aircraft Material Fire Test Handbook DOT/ FAA/AR-00/12, chapters 1.0 - 4.0 (FAR 25.853, 25.855, 25.1359)
Scope of application:
Determination of the combustion performance of non-metallic materials used in civil aircraft cabin, the airworthiness identification of non-metallic materials in the cabin. Test type: horizontal test, vertical test, 45-degree tilt combustion test, 60-degree tilt combustion test.
Specimen holder kits:
Horizontal Holder - for Horizontal Bunsen Burner Test for Cabin and Cargo Compartment Materials Chapter 3.0, DOT/FAA/AR-00/12
Vertical Holder - for Vertical Bunsen Burner Test for Cabin and Cargo Compartment Materials Chapter 1.0, DOT/FAA/AR-00/12
45° Holder - for 45° Bunsen Burner Test for Cabin and Cargo Compartment Materials Chapter 2.0, DOT/FAA/AR-00/12
60° Holder - for 60° Bunsen Burner Test for Electric Wire Chapter 4.0, DOT/FAA/AR-00/12
Standard Features:
Gas control system
Local gas pressure regulator and gauge
Gas flow indicator lamps
Three digital specimen event timers with remote control
Automatic gas shut off during power failure
Burner positioning apparatus
Sliding tempered glass viewing window
Hand access openings with doors for closed window access
Interior light
Meets or exceeds CE safety requirements
Technical Specifications:
| Physical dimensions (W x H x D) |
Interior: 122cm (48”) x 114cm (45”) x 51cm (20”)
Exterior: 122cm (48”) x 140cm (55”) x 51cm (20”)
|
| Weights |
Bench: 124kg (275lbs) Shipping: 181kg (400lbs) |
| Electrical |
120V, 60Hz, 1.5A or 230V, 50Hz, 0.75A |
Testing requires customer-supplied technical grade methane
(minimum 99% purity) at 20-40 PSI
