ISO 834-1 Horizontal Fire Resistance Test Furnace for Floor Beam Roof Slab

Large Image : ISO 834-1 Horizontal Fire Resistance Test Furnace for Floor Beam Roof Slab

Product Details:

Place of Origin:	Guangdong, China
Brand Name:	Daxian
Certification:	ISO 9001:2015, ISO 834-1
Model Number:	DX8364

Payment & Shipping Terms:

Minimum Order Quantity:	1 Set
Price:	USD 25000-50000 / Set
Packaging Details:	Export-grade wooden case with moisture-proof film and shock-absorbing foam
Delivery Time:	50-70 days for production
Payment Terms:	T/T,L/C
Supply Ability:	3 Sets per Month

Contact Now

ISO 834-1 Horizontal Fire Resistance Test Furnace for Floor Beam Roof Slab

Description

Test Standard:	ISO 834-1, GB/T 9978.1	Furnace Type:	Horizontal
Max Temperature:	1250 C	Furnace Interior Size:	4200 X 4008 X 1500 Mm
Specimen Fire Area:	4200 X 4800 Mm	Burner Type:	High-speed Gas Burner
Fuel:	Propane / Natural Gas	Control System:	PLC + Touch Screen
Temperature Accuracy:	+/- 15 C	Pressure Accuracy:	+/- 2 Pa
Highlight:	ISO 834-1 fire resistance test furnace , horizontal fire test furnace , floor beam fire testing equipment

Horizontal Fire Resistance Test Furnace for Floors, Beams and Roof Slabs

The DX8364 Horizontal Fire Resistance Test Furnace is designed to evaluate the fire resistance performance of horizontal building components such as floors, beams and roof slabs under the standard ISO 834-1 time-temperature curve. It is suitable for fire research institutes, construction material testing laboratories and third-party certification bodies.

Test Scope

Fire resistance testing of reinforced concrete floors and slabs
Fire resistance testing of load-bearing and non-load-bearing beams
Fire resistance testing of roof slabs and ceiling components
Temperature measurement at selected points of different cross-sections and depths

Key Features

Compliant with ISO 834-1 and GB/T 9978.1 fire resistance test standards
Furnace temperature up to 1250 C with high-precision K-type thermocouples
PLC temperature and pressure control system with real-time data acquisition
Propane or natural gas high-speed burner heating system
Furnace pressure control accuracy of +/- 2 Pa

Technical Parameters

Furnace Type	Horizontal
Max Temperature	1250 C
Furnace Interior Size	4200 x 4008 x 1500 mm
Specimen Fire Area	4200 x 4800 mm
Control System	PLC + touch screen
