ISO 5660-1 Cone Calorimeter Heat Release Rate Tester Fire Testing Equipment for Building Material

ISO 5660-1 Cone Calorimeter Heat Release Rate Tester Fire Testing Equipment for Building Material
ISO 5660-1 Cone Calorimeter Heat Release Rate Tester Fire Testing Equipment for Building Material ISO 5660-1 Cone Calorimeter Heat Release Rate Tester Fire Testing Equipment for Building Material ISO 5660-1 Cone Calorimeter Heat Release Rate Tester Fire Testing Equipment for Building Material ISO 5660-1 Cone Calorimeter Heat Release Rate Tester Fire Testing Equipment for Building Material

Large Image :  ISO 5660-1 Cone Calorimeter Heat Release Rate Tester Fire Testing Equipment for Building Material

Product Details:
Place of Origin: China
Brand Name: EcerTech
Certification: ISO 5660-1, ASTM E1354, EN 45545-2
Model Number: DX834A8
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: $18,000 - $32,000 per Set
Packaging Details: Standard Export Plywood Case with Vacuum-packed Shockproof Foam Protection
Delivery Time: 15-25 Working Days
Payment Terms: T/T,L/C at sight,Western Union
Supply Ability: 50 Sets per Month
Contact Now

ISO 5660-1 Cone Calorimeter Heat Release Rate Tester Fire Testing Equipment for Building Material

Description
Test Standard: ISO 5660-1, ASTM E1354, EN 45545-2 Heat Flux Range: 0-100 KW/m²
Oxygen Analyzer: Paramagnetic, 0-25% O₂ Sample Size: 100 Mm × 100 Mm
Ignition Method: Electric Spark Igniter Exhaust Flow Rate: 0.012-0.035 M³/s
Mass Loss Resolution: 0.01 G Smoke Measurement: Laser Extinction System
Data Acquisition: 24-bit ADC With PC Software
Highlight:

ISO 5660-1 cone calorimeter fire testing equipment

,

heat release rate tester for building materials

,

fire testing equipment with ISO 5660-1 standard

ISO 5660-1 Cone Calorimeter CT-CC2000

Precision Heat Release Rate Testing for Building Materials · Polymers · Textiles · Railway Components

Fully Compliant with ISO 5660-1 · ASTM E1354 · EN 45545-2

Product Overview

The Cone Calorimeter is a state-of-the-art fire testing instrument designed to evaluate the heat release characteristics of materials exposed to controlled levels of radiant heating. By measuring the oxygen consumption during combustion, this apparatus provides critical data including Heat Release Rate (HRR), Smoke Production Rate (SPR), and Mass Loss Rate (MLR) — essential parameters for fire safety engineering and material R&D.

Engineered for research laboratories, certification bodies, and manufacturing quality control departments, the machine delivers repeatable, high-precision results across a wide range of materials: building products, cable sheathing, automotive interiors, aircraft components, and marine applications.

Key Features

🔬 High-Precision Oxygen Analysis

Paramagnetic oxygen analyzer with 0-25% O₂ measurement range delivers accurate oxygen depletion data for reliable HRR calculation per oxygen consumption calorimetry principles.

🔥 Adjustable Heat Flux

Conical radiant heater provides 0-100 kW/m² heat flux with uniform irradiation across the entire 100 mm * 100 mm sample surface, ensuring consistent test conditions.

💨 Integrated Smoke Measurement

Laser extinction system measures smoke production rate and specific extinction area in real time, enabling comprehensive fire hazard assessment in a single test run.

📊 Advanced Data Acquisition

24-bit ADC with dedicated PC software for real-time data logging, curve plotting, and automatic report generation in compliance with ISO 5660-1 reporting requirements.

🎯 Automatic Ignition

Reliable electric spark igniter with automatic positioning and retraction mechanism, eliminating operator variability and ensuring consistent ignition timing across repeated tests.

🛡️ Multi-Standard Compliance

Conforms to ISO 5660-1, ASTM E1354, and EN 45545-2 standards. Suitable for building material certification, railway fire safety (EN 45545), and maritime applications.

Measured Parameters

Parameter Symbol Unit Standard
Heat Release Rate HRR kW/m² ISO 5660-1
Total Heat Release THR MJ/m² ISO 5660-1
Smoke Production Rate SPR m²/s ISO 5660-1
Mass Loss Rate MLR g/s ISO 5660-1
Time to Ignition TTI s ISO 5660-1
Specific Extinction Area SEA m²/kg ISO 5660-1

Applications

🏗️
Building Materials
Wall panels, insulation, flooring, roofing membranes
🧵
Textiles & Upholstery
Curtains, furniture fabrics, mattresses, protective clothing
🚆
Railway Components
EN 45545-2 seat materials, interior panels, cable conduits
🚗
Automotive Interiors
Dashboard materials, seat covers, headliners, door panels
🔌
Cables & Polymers
Electrical cable sheathing, plastic compounds, composite materials
✈️
Aerospace Materials
Cabin interior panels, thermal insulation, composite structures

Why Choose CT-CC2000 Cone Calorimeter?

±1%

O₂ Measurement Accuracy

0-100

kW/m² Heat Flux Range

3-Std

ISO/ASTM/EN Compliance

24/7

Technical Support

📦 Package Includes

  • ✅ Cone Calorimeter Main Unit
  • ✅ Paramagnetic Oxygen Analyzer
  • ✅ Laser Smoke Measurement System
  • ✅ Mass Loss Load Cell (0.01 g resolution)
  • ✅ Electric Spark Igniter Assembly
  • ✅ Exhaust Duct with Thermocouples
  • ✅ Data Acquisition Hardware & Software
  • ✅ Calibration Kit & User Manual
