ASTM D149 Test Machine 100KV Electrical Strength Testing Equipment As Per IEC 60243-1 Lab Testing Apparatus

Large Image : ASTM D149 Test Machine 100KV Electrical Strength Testing Equipment As Per IEC 60243-1 Lab Testing Apparatus

Product Details:

Place of Origin:	China
Brand Name:	DAXIAN
Certification:	IEC60243-1, IEC60243-2, ASTM D149
Model Number:	DX8388A

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Negotiable
Packaging Details:	Wooden case
Delivery Time:	30 days after order confirmed
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram, In cash
Supply Ability:	30 sets per month

Contact Now

ASTM D149 Test Machine 100KV Electrical Strength Testing Equipment As Per IEC 60243-1 Lab Testing Apparatus

Description

Breakdown Voltage:	0~100kV	Applicable:	Insulating Materials
Standard:	IEC 60243-1	Booting Speed:	100, 200, 500, 1000, 2000, 5000（KV/S）
Accuracy:	≤ 2％	Weight:	200kg
Dimension:	L1400* W1040* H1500 Mm	Transformer Capacity:	10 KVA
Highlight:	ASTM D149 test machine 100KV , electrical strength testing equipment IEC 60243-1 , lab testing apparatus for rubber

100KV IEC 60243-1 Power Frequencies Electrical Strength Testing Equipment

Application:

This tester is suitable for measuring the breakdown strength and withstand voltage time of solid insulating materials such as plastic, film, resin, mica, ceramics, silica gel, glass, insulating paint, etc. in air or liquid medium, it can measure the breakdown strength and withstand voltage time under power frequency (48 ~ 62Hz) or corresponding DC voltage.

Standards:

IEC60243-1

IEC60243-2

Specifications:

Breakdown voltage	0~50kV
Booting speed	100,200,500,1000,2000,5000(KV/S)
Voltage measurement accuracy	≤ 2％
The leakage current selection	1~100 mA
Methods of test	DC & AC
Supply power	AC220V 50/60Hz
Dimension	L 1400* W 1040* H 1500 mm
Weight	200kg

1. Booting speed control: Electrical automatic control

2. Methods of booting: Automatic program-controlled

3. Power Frequency: sine wave 50Hz/60HZ

4. Transformer capacity: 10 KVA

5. AC 0~50 KV (continuously adjustable)
