0-250V Output Voltage Regulator Electric Trace Resistance Index Tester With 0.5% Dropping Accuracy Adjustable Design

0-250V Output Voltage Regulator Electric Trace Resistance Index Tester With 0.5% Dropping Accuracy Adjustable Design
0-250V Output Voltage Regulator Electric Trace Resistance Index Tester With 0.5% Dropping Accuracy Adjustable Design 0-250V Output Voltage Regulator Electric Trace Resistance Index Tester With 0.5% Dropping Accuracy Adjustable Design 0-250V Output Voltage Regulator Electric Trace Resistance Index Tester With 0.5% Dropping Accuracy Adjustable Design 0-250V Output Voltage Regulator Electric Trace Resistance Index Tester With 0.5% Dropping Accuracy Adjustable Design

Large Image :  0-250V Output Voltage Regulator Electric Trace Resistance Index Tester With 0.5% Dropping Accuracy Adjustable Design

Product Details: Payment & Shipping Terms:
Price: CN¥17,857.25/sets 1-1 sets
Contact Now

0-250V Output Voltage Regulator Electric Trace Resistance Index Tester With 0.5% Dropping Accuracy Adjustable Design

Description
Warranty: 1-5Years Customized Support: OEM, ODM, OBM, Software Reengineering
Place Of Origin: Guangdong, China Brand Name: DAXIAN
Power: 6000W Voltage: 220V
Type: Testing Machine Application: Plastic Testing, Laboratory Testing
Protection Class: Ip67 Electrode: 0.5mm Thick
Voltage Regulator Output: Adjustable From 0~250V Material: Stainless Steel
Test Voltage: 100V-6000V Stepless Adjustable Voltage Stability: ± 1%
Capacity: 5KVA Dropping Accuracy: 0.5%
Test Time: 6-10 Hours Weight: Approximately 200KG
Distance Between Electrodes: 50.0mm ± 0.1
Highlight:

Adjustable Voltage Regulator

,

Electric Trace Resistance Index Tester

,

0-250V Voltage Regulator

Product Description
0-250V Output Voltage Regulator Electric Trace Resistance Index Tester With 0.5% Dropping Accuracy Adjustable Design 0
0-250V Output Voltage Regulator Electric Trace Resistance Index Tester With 0.5% Dropping Accuracy Adjustable Design 1
0-250V Output Voltage Regulator Electric Trace Resistance Index Tester With 0.5% Dropping Accuracy Adjustable Design 2
0-250V Output Voltage Regulator Electric Trace Resistance Index Tester With 0.5% Dropping Accuracy Adjustable Design 3
Company Profile
0-250V Output Voltage Regulator Electric Trace Resistance Index Tester With 0.5% Dropping Accuracy Adjustable Design 4
0-250V Output Voltage Regulator Electric Trace Resistance Index Tester With 0.5% Dropping Accuracy Adjustable Design 5
0-250V Output Voltage Regulator Electric Trace Resistance Index Tester With 0.5% Dropping Accuracy Adjustable Design 6
Dongguan Daxian Automation Instrument and Equipment Co., Ltd., founded on July 5, 2012, is located in Chang'an Town, Dongguan City, the Pearl River Delta, Guangdong Province, with developed transportation. It is a private enterprise engaged in the production, design, development and sales of test equipment and instruments. After years of development, the company has established a strong professional research and development team, committed to the research and development of test instruments and non-standard automation equipment.
Packing & Delivery
Selection of Packaging Materials： Selection of Packaging Materials 1. Use sturdy and durable packaging boxes to prevent equipment damage caused by collision or compression during transportation. 2. The interior is filled with shockproof materials, such as foam, air cushion or pearl cotton, to ensure that the equipment will not shake in the packaging box. 3. For fragile or sensitive components (such as electrodes, display screens, etc.), package and secure them separately to avoid damage during transportation.
Mode of Transport： 1. Prioritize choosing professional logistics and transportation companies to ensure safety and reliability during transportation. 2. For long-distance transportation, land or sea transportation should be used to avoid the potential impact of air pressure changes on equipment during air transportation.
0-250V Output Voltage Regulator Electric Trace Resistance Index Tester With 0.5% Dropping Accuracy Adjustable Design 7
0-250V Output Voltage Regulator Electric Trace Resistance Index Tester With 0.5% Dropping Accuracy Adjustable Design 8
Specification
Item
Value
Warranty
1-5Years
Customized support
OEM, ODM, OBM, Software reengineering
Place of Origin
China
Guangdong
Brand Name
DAXIAN
Model Number
DX8427
Power
Electronic
Electrode
0.5mm thick
Material
Stainless steel
Distance between electrodes
50.0mm ± 0.1
Test voltage
100V-6000V stepless adjustable
Voltage regulator Output
Adjustable from 0~250V
Capacity
5KVA
Test time
6 hours
Dropping accuracy
0.5%
Voltage stability
± 1%
Scope of application:
High-voltage leakage testing machine mainly suitable for testing the resistance of electrical and electronic products, household appliances, and their materials to electrical trace and corrosion, simulating the use of liquid pollutants and inclined surface specimens at power frequency (48Hz -62Hz). Evaluate the resistance level of electrical insulation materials used under harsh environmental conditions through the measurement of resistance to electrification and corrosion..Under the influence of moisture and impurities in electrical products, insulation leakage may occur between charged parts of different polarities or between
charged parts and grounded metal. The resulting arc can cause breakdown, short circuit, or material erosion due to discharge, and even lead to fire. This tester is a destructive test that simulates the above situation on insulation materials, used to measure and evaluate the relative resistance to leakage and marking of insulators under the action of an electric field and impurity containing water at a specified voltage. It is suitable for solid electrical insulation materials and their products in electrical and electronic products, household appliances, such as relay sockets, conversion switch covers, contactors, etc.

Compliant with standards:
According to the requirements of GB/T6553-2014/IEC60587-1984 "Test Method for Evaluating
the Resistance of Electrical Insulation Materials to Tracing and Corrosion under Severe Environmental Conditions" and DL/T810-2002 "Technical Conditions for ± 500kV DC Rod Suspension Composite Insulators", the simulation test items specified in the standard for AC/DC Leakage Tracing Test of Insulation Materials, applicable to rubber, plastic and other electrical insulation materials such as inclined plane method. Standard for five sets of silicone rubber testers and silicone testers.

FAQ
1. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

2.what can you buy from us?
Fire Testing Equipment,Construction Materials Testing Equipment,Plastic Testing Equipment,Wire Testing Equipment,Environmental Test Chamber

3. why should you buy from us not from other suppliers?
Advanced technology research and development capabilities, high-quality product manufacturing and testing capabilities, rich industry experience and professional knowledge, as well as good customer relationships and reputation.

4. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,HKD,CNY;
Accepted Payment Type: T/T,L/C,MoneyGram,PayPal,Western Union;
Language Spoken:English,Chinese

5.What are the test methods for evaluating the resistance to electrical traces and corrosion of electrical insulation materials used under harsh environmental conditions？
Method 1: Constant voltage tracing method;
Method 2: Stepwise voltage tracing method.
After Service


1. Ensure the high quality of the product.
2. Packaging can be done according to customer requirements and pictures can be attached
before shipment.
3. Provide the fastest response to maintenance and assistance requests from users. After the user submits a maintenance request,ensure to provide professional technical support in the shortest possible time and in the fastest way possible.
4. Our engineers provide professional after-sales service.
5. The warranty period is 12 months. During the warranty period, we are responsible for providing free maintenance, upkeep, and replacement of damaged and defective parts (under normal use) for the user's equipment. After the free warranty ends, service fees will be charged at your discretion.
