DX 8298 Flammability Testing Machine BS476-6 Standard For Building Materials

Description
Product Name: BS476-6 Fire Propagation Tests On Building Materials And Structures Standard: BS 476-6
Test Chamber Inner Dimension: 190 Mm × 190 Mm × 90 Mm Air Inlet: 96 Mm × 25 Mm
Asbestos Cement Board: 12.5 Mm Thick Warranty: 12 Months
High Light:

Flammability Testing Machine BS476-6

,

Fire Testing Equipment BS476-6

,

12.5 mm thick Flammability Testing Machine

BS476-6 Fire Propagation Tests On Building Materials And Structures Flammability Test Machine



BS476-6 Fire propagation Tests on Building materials and structures



Model: DX8298


Meet the standards:


BS 476 Part 6 .



Scope of application:



The test device is suitable for testing the fire spread index of wall and ceiling lining and other flat materials, composite materials or components, so as to evaluate the performance of inner wall and ceiling lining.





1. Export to Malaysia, Switzerland

2. Test gas G112 (17% methane, 59% hydrogen, 24% nitrogen)

3. Heating element: two 1000W quartz heating tubes





Technical parameters:



Chamber wall:



Asbestos cement board

12.5 mm thick

Dry density

1300 kg / m3 ~ 1450 kg / m3

test chamber inner dimension

190 mm × 190 mm × 90 mm

Air inlet

96 mm × 25 mm

Mica observation window

50 mm × 50 mm

Steel baffle

200 mm × 40 mm

Steel bar

fixed sample holder





DX 8298 Flammability Testing Machine BS476-6 Standard For Building Materials 0



Panel description :



(1) Gas Pressure : display the input gas pressure, unit: MPa;

(2) Wattmeter: display and measure the input voltage, current and power of the heating tube;

(3) Pressure adj.: adjust the input gas pressure, and display the pressure value through (1);

(4) Manometer: display the output gas pressure value, unit: KPa ;

(5) Alarm: when the equipment fails or the test ends, it will sound an alarm as a reminder;

(6) Power: control the general power supply of the equipment, in the open state, the indicator light is on, and the off indicator light is off.



DX 8298 Flammability Testing Machine BS476-6 Standard For Building Materials 1
