DX8426 Smoke Density Test Machine ASTM D2843 Standard

The DX8426 Smoke Density Test Machine is suitable for the determination of static smoke production during the combustion of building materials and their products, and can also be used for the determination of static smoke production during the combustion of other solid materials.

Testing apparatus for ASTM D2843.

• Automatic timing, automatic ignition and automatic smoke exhaust; the luminous flux can be automatically calibrated
• computer control with a complete set of transmittance measurement software, capable of outputting curve reports, automatically saving data and printing
• Smoke density measurement range: 0~100%, accuracy: ±3%
• Optoelectronic system with 15W / 6V bulb light source; silicon photovoltaic cell receiver ensures accurate luminous flux detection
• Powerful exhaust fan discharges exhaust gas outdoors after testing
• This machine consists of a combustion chamber and a computer control system

• Gas source: 95% propane gas, or gas of equivalent purity (provided by the customer)
• Combustion lamp: native lamp with a length of 260mm and a nozzle diameter of 0.13mm, forming a 45° angle with the smoke box
• Processed focal length: 60~65mm
• Working pressure of main burner: 276KPa (adjustable)
• Auxiliary burner pressure: 138KPa (adjustable)
• Combustion box size: L300 * W300 * H790 (mm)
• Power supply voltage: AC220V, 50Hz; maximum operating power: 0.7KW
