Product Details:
|
Application: | Wire And Cable Insulation Coating Materials | Vertical Combustion Box: | 305*355*610mm |
---|---|---|---|
Horizontal Combustion Box: | 305*355*610mm | Power Supply:: | 220VAC, 50Hz |
Weight: | 40kg | Standards: | UL1581 |
Highlight: | vibration testing equipment,button life testing machine |
Wire and Cable Vertical Horizontal Combustion Tester
Product Description:
Applicable to a variety of wire and cable insulation coating materials, printed circuit board materials, IC insulation and other organic materials of the combustion resistance test. Test, the test piece to the top of the flame, burn 15 seconds, extinguish 15 seconds, repeat 5 times After the inspection of the specimen was burned, it can set the burning, the extinguishing time and the number of repetitions, and can be operated automatically.
Compliance with the standards: VW-1 in compliance with UL1581.UL13.UL444.UL1655 and FT-1 test standard requirements for CSA.
Technical Parameters:
Vertical combustion box: Made according to UL1581 standard size, internal dimensions are 305*355*610mm.
Horizontal combustion box: According to UL1581 standard size, the internal size is 305*355*610mm.
Vertical spark nozzle: The nozzle angle is 20 degrees with a gas control valve.
Horizontal spark nozzle: The nozzle angle is 90 degrees with a gas control valve.
Vertical or horizontal nozzle selection mode.
Select manual/automatic mode.
When the preset data is reached, the machine automatically stops the test.
Fuel: Gas. Methane (Customer-supplied)
Power supply: 220VAC, 50Hz
Weight: 40kg
