Product Details:
|
| Breakdown Voltage: | 0~50kV | Applicable: | Insulating Materials |
|---|---|---|---|
| Booting Speed: | 100,200,500,1000,2000,5000（KV/S） | Accuracy: | ≤ 2％ |
| Dimension: | L1400* W1040* H1500 Mm | Methods Of Test: | DC & AC |
| Transformer Capacity: | 10 KVA | Weight: | 200kg |
| High Light: | IEC 60243-1 Material Testing Machine,50kV Insulating Material Testing Machine,ASTM D149 Insulating Material Testing Machine |
||
Apply to continuous uniform boosting or step by step boosting way, step by step toward a sample breakdown, ac/dc voltage until the breakdown voltage measurement, calculation of the sample breakdown strength.
Breakdown Voltage: Sample under a certain voltage is punctured, at this time of voltage named breakdown voltage, expressed as a kV.
Voltage Resistance Value: Quickly to keep the voltage to the specified value, sample time is not breakdown, according to the voltage value of withstanding voltage value of the sample, expressed as a kV.
Breakdown Strength: The ratio of the sample breakdown voltage and its thickness named breakdown strength, expressed a KV/mm.
| Breakdown voltage | 0~50kV |
| Booting speed | 100,200,500,1000,2000,5000(KV/S) |
| Booting speed control | Electrical automatic control |
| Voltage measurement accuracy | ≤ 2％ |
| The leakage current selection | 1~100 mA |
| Methods of test | DC & AC |
| Methods of booting | Automatic program-controlled |
| Power Frequency | sine wave 50Hz/60HZ |
| Supply power | AC220V 50/60Hz |
| Dimension | L 1400* W 1040* H 1500 mm |
| Weight | 200kg |
| Transformer capacity | 10 KVA |
| AC 0~50 KV (continuously adjustable) | |
