Product Details:
|
| Standard: | IEC61730 | Inside Size: | 700 X 400 X 810mm |
|---|---|---|---|
| Open Area: | 25x25mm, Height: 50mm | Burner: | 45° Angle, Flame Height: 20mm |
| Timer: | 0-99.99s/MH Can Be Set | Supply Power: | 220V |
| High Light: | IEC 61730 Flammability Testing Equipment,Photovoltaic Module Cell Flammability Tester |
||
|
Serial number
|
Parts
|
Parameters
|
|
1
|
Intake fan and intake guide device
|
Introduce outdoor air, adjustable fins to avoid air turbulence.
The inlet fan can be controlled remotely.
|
|
2
|
Anemometer
|
At least 3 anemometers, the wind speed reaches 5.3 ± 0.2 m/s;
The accuracy of the anemometer is 0.2m/s;
|
|
3
|
Air flue
|
Air duct material, stainless steel.
The height of the air duct from the ground: 1111 ± 100 mm;
The internal dimensions of the air duct: 2133.6 ± 100 mm * 762mm;
The length of the air duct: the temperature at three points reaches 5.3 ± 0.2 m/s.
|
|
4
|
Burner
|
Burner size: refer to UL790;
Burner length: 1,120mm ± 0.1 mm;
Burner inner diameter and outer diameter: inner diameter is 50.9 mm ± 0.1 mm, outer diameter is 60.3 ± 0.1 mm;
Nozzle size: (12.7 ± 0.1) mm X (910.0 ± 1.5) mm (width X length);
Ports on both sides: inner diameter (25 ± 0.13 mm) and outer diameter 33.4 ± 0.13 mm);
With automatic ignition function and equipped with ignition gun;
|
| 5 |
Anti-backboard
|
Install between the test frame and the air duct, and place the flame recoil.
|
| 6 |
Air duct thermocouple
|
Monitor the air temperature in the air duct
|
